SOLID CARBIDE ENDMILLS ETI
Series
FVT 7021 - FVT 9081
• First Choise for Titanium OAL
• Variable Helix & Pitch APMX RE
• Finishing
• High Speed Machining DCONMS
• AlTiN Coating 10% Submicron Carbide
DC
7-9 V°
Flutes Helix S
DC APMX DCONMS NOF OAL RE Shank EDP Number
6.0 13 6 7 57 0.2 C 3402485
8.0 19 8 7 63 0.4 C 3401810
10.0 22 10 7 72 0.5 C 3401811
12.0 26 12 7 83 0.6 C 3402486
12.0 26 12 7 83 0.6 W 3402487
16.0 32 16 9 92 0.8 C 3402488
ap
ae
Side Milling
Side Milling Fz mm/t
Vc (m/min) ap ae Ø 6-8 Ø 10-12 Ø16
Titanium 50-70 2D 0.4xD 0.03-0.045 0.06-0.08 0.065-0.08
Inconel 15-30 2D 0.4xD 0.02-0.040 0.02-0.045 0.05-0.07
Cutting Data for HIGH SPEED MACHINING
ap
ae
Side Milling
Side Milling Fz mm/t
Vc (m/min) ap ae Ø 6-8 Ø 10-12 Ø16
Titanium 70-110 2D 0.1xD 0.04-0.08 0.04-0.05 0.04-0.06
Inconel 25-50 D 0.1xD 0.03-0.06 0.05-0.08 0.05-0.09
